Product number: IFP20100140-15S2P-48V-60Ah

Cell model: IFP20100140A-30Ah 3.2V

Battery specification: IFP20100140-15S2P-48V-60Ah

Nominal voltage: 48V

Nominal capacity: 60Ah

Charging voltage: 54V

Charging current: ≤6A

Discharge current: ≤50A

Discharge cut-off voltage: 33.73V

Internal resistance of finished product: ≤100mΩ

Battery weight: 33Kg

Charging temperature: 0 ~ 45℃

Discharge temperature: -10 ~ 55 ℃

Product size: 400*260*170mm (Max)

Storage temperature: -20 to +45 ° C (less than 1 month) -20 to 35 ° C (less than 3 months); -20~+25℃ (less than 12 months)

Battery package: black metal case

Communication protocol: CAN

Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, over temperature protection, etc.

Application: Monorail detection vehicle
